Roof Panel Systems

1" Double Lock Standing Seam

SS100

A mechanically seamed, double-lock architectural standing-seam roof panel with a 1" seam, fabricated to project specifications.

Request a Quote →
1" double lock standing seam metal roofs on dormers of a shingled house
Profile Overview
1"
Cross section — SS100 / SP1-100P

Profile geometry per manufacturer drawing SS100 / SP1-100P.

System Information
Seam height
1"
Seam type
Mechanically seamed, double lock
Attachment
Concealed clip
Fabrication
Made to order, fabricated in Central Ohio
Panel width
To be confirmed
Gauges
To be confirmed
Panel lengths
To be confirmed
Testing + approvals
To be confirmed
Warranty
To be confirmed
Available Materials
Galvalume Steel
Mill finish
Painted Steel
Colors to be confirmed
Aluminum
Mill and painted
Copper
Natural finish
Stainless Steel
To be confirmed
Zinc
To be confirmed
Materials + Finishes →
Panel Options
Panel lengths
Cut to project dimensions
Clips + fasteners
To be confirmed
Coverage widths
To be confirmed

Options marked to be confirmed will be published once verified.

More than the panel.

Mid-Ohio Metals can fabricate the complete trim package for your standing-seam roof system. Send us your dimensions or project details and we’ll fabricate the trim to match the requirements of the job. Trim is produced to project dimensions rather than predetermined stock sizes.

  • Eave Trim
  • Rake / Gable Trim
  • Ridge
  • Hip
  • Valley
  • Headwall
  • Sidewall
  • Transition Flashing
  • Coping
  • Custom Flashing
Request Panel + Trim Package →
Request This Panel

Send your dimensions and we’ll price it.

The request form opens with 1" Double Lock Standing Seam already selected. Attach a drawing or plan if you have one.

Request a Quote →
