Roof Panel Systems

FF-100 — 1" Snap Lock

FF-100

An architectural standing-seam roof panel with an approximately 1" profile and snap-lock panel connection, fabricated to project specifications.

Request a Quote →
Profile Overview
1"
Cross section — FF100 / FF1-FF1

Profile geometry per manufacturer drawing FF100 / FF1-FF1.

System Information
Seam height
Approximately 1"
Seam type
Snap lock
Attachment
Concealed
Fabrication
Made to order, fabricated in Central Ohio
Panel width
To be confirmed
Gauges
To be confirmed
Panel lengths
To be confirmed
Testing + approvals
To be confirmed
Warranty
To be confirmed
Available Materials
Galvalume Steel
Mill finish
Painted Steel
Colors to be confirmed
Aluminum
Mill and painted
Copper
Natural finish
Stainless Steel
To be confirmed
Zinc
To be confirmed
Materials + Finishes →
Panel Options
Panel lengths
Cut to project dimensions
Clips + fasteners
To be confirmed
Coverage widths
To be confirmed

Options marked to be confirmed will be published once verified.

More than the panel.

Mid-Ohio Metals can fabricate the complete trim package for your standing-seam roof system. Send us your dimensions or project details and we’ll fabricate the trim to match the requirements of the job. Trim is produced to project dimensions rather than predetermined stock sizes.

  • Eave Trim
  • Rake / Gable Trim
  • Ridge
  • Hip
  • Valley
  • Headwall
  • Sidewall
  • Transition Flashing
  • Coping
  • Custom Flashing
Request Panel + Trim Package →
Request This Panel

Send your dimensions and we’ll price it.

The request form opens with FF-100 — 1" Snap Lock already selected. Attach a drawing or plan if you have one.
